Magnetic Stripe Card:

TRACK 1 / IATA / 210 pbi / 79 Alphanumeric Characters
TRACK 2 / ABA / 75 bpi /40 Numeric Characters
TRACK 3 / Thrift / 210 bpi / 107 Numeric Characters
5-7 bit auto-detect Track 3

Password:

Yes - optional

RS232 Interface:

RS232, Half-Duplex, 8N1, 9600 bps

Date and Time Stamp

Built-in time clock for stamping each transaction with the date and time

Memory Size for Storing Data:

Serial Electrically Erasable PROMs (EEPROM) 512K bytes

Battery Power:

6F22DN 9V / 006P and Low Battery Detect

Power Supply:

DC 8V ~ 12V, 300mA

Dimensions:

4"L x 1.25"W x 2.25" H
D 100mm L x 33mm W x 58 mm H

Weight:

4 oz.

Environment:

Operating Temp: 0 ~ 55 Deg.C
Storage Temp: -10 ~ 55 Deg.C
Humidity: 10~90 % relative

Mounting:

Portable or Any surface
